Cylindrical antivibration foot mounts type E (F) are female-mounted vibration dampers, ideal for reducing vibrations and noise effectively. Made of natural rubber with galvanised steel reinforcement, they ensure stability and ease of installation. Perfect for light machinery, industrial systems and mechanical equipment, they offer strength and flexibility. Available in different hardnesses to meet specific needs, they combine high performance with a compact and functional design.
Cylindrical vibration dampers with a female foot (PF), i.e. female connection (internal thread or housing), are used to reduce vibrations and oscillations in systems that require secure attachment to the base with simultaneous vibration isolation. They are widely used in industrial equipment, such as machine tools, pumps, compressors, and in heating, ventilation and air conditioning (HVAC) systems.
The foot construction allows the vibration damper to be firmly anchored to a surface, while the female connection facilitates connection to externally threaded components, simplifying assembly and disassembly. This makes them particularly useful in applications where fastening stability and quick integration into existing systems is essential.
These cylindrical PF vibration dampers effectively absorb vibration energy, reducing mechanical stress on equipment and preventing premature wear. They help minimise noise, improve the operational safety of systems and protect against material fatigue failure.
For example, in production departments, they help limit the transmission of vibrations from heavy machinery to foundations, improving working conditions and extending the life of structures. The compact cylindrical shape and the versatility of the female connection allow them to be used in a variety of conditions, including aggressive environments, while the foot provides greater stability, making these vibration dampers a versatile solution for many engineering applications.
Download the Cylindrical antivibration foot mounts type E (F) catalogue in pdf format:
| Article | Dimensions | Load (daN) 55Sh | Rocam | Stainless Steel | ||
| øD | h | øC | ||||
| PF 0001 08 | 10 | 8 | 4 | 6,5 | 95647 | |
| PF 0001 58 | 15 | 8 | 4 | 20 | 95648 | |
| PF 0001 58M5 | 15 | 8 | 5 | 20 | 95648M5 | |
| PF 0001 69 | 16 | 9 | 4 | 20 | 95649 | |
| PF 000208 | 20 | 8 | 6 | 40 | 95650 | |
| PF 001 01 0 | 10 | 10 | 4 | 5 | 95651 | |
| PF 001 01 5 | 10 | 15 | 4 | 4 | 95652 | |
| PF 001 31 0 | 13 | 10 | 5 | 4,8 | 95653 | |
| PF 001 31 3 | 13 | 13 | 5 | 6,7 | 95654 | |
| PF 001 31 5 | 13 | 15 | 5 | 6,7 | 95655 | |
| PF 001 320 | 13 | 20 | 5 | 6,7 | 95656 | |
| PF 001 320M6 | 13 | 20 | 6 | 6,7 | 95656M6 | |
| PF 001 51 0 | 15 | 10 | 4 | 20 | 95 173 | 951 73X |
| PF 001 51 0M5 | 15 | 10 | 5 | 20 | 951 73M5 | 951 73M5X |
| PF 001 51 3 | 15 | 13 | 4 | 20 | 95978 | |
| PF 001 51 3M5 | 15 | 13 | 5 | 20 | 95978M5 | |
| PF 001 51 5 | 15 | 15 | 4 | 9 | 95 174 | 951 74X |
| PF 001 51 5M5 | 15 | 15 | 5 | 9 | 951 74M5 | 951 74M5X |
| PF 001 520 | 15 | 20 | 4 | 20 | 95 175 | 951 75X |
| PF 001 520M5 | 15 | 20 | 5 | 20 | 951 75M5 | 951 75M5X |
| PF 001 525 | 15 | 25 | 4 | 20 | 95657 | |
| PF 001 525M5 | 15 | 25 | 5 | 20 | 95657M5 | |
| PF 001 530 | 15 | 30 | 4 | 20 | 95658 | |
| PF 001 530M5 | 15 | 30 | 5 | 20 | 95658M5 | |
| PF 001 532 | 15 | 32 | 4 | 20 | 95659 | |
| PF 001 532M5 | 15 | 32 | 5 | 20 | 95659M5 | |
| PF 001 61 0 | 16 | 10 | 5 | 15 | 95660 | |
| PF 001 61 5 | 16 | 15 | 5 | 13,5 | 95661 | |
| PF 001 620 | 16 | 20 | 5 | 12 | 95662 | |
| PF 001 625 | 16 | 25 | 5 | 15 | 95663 | |
| PF 00201 0 | 20 | 10 | 6 | 30 | 95 176 | 951 76X |
| PF 00201 3 | 20 | 13 | 6 | 23 | 95664 | |
| PF 00201 5 | 20 | 15 | 6 | 26 | 95 177 | 951 77X |
| PF 00201 7 | 20 | 17 | 6 | 30 | 95665 | |
| PF 002020 | 20 | 20 | 6 | 30 | 95 178 | 951 78X |
| PF 002025 | 20 | 25 | 6 | 30 | 95 179 | 951 79X |
| PF 002030 | 20 | 30 | 6 | 30 | 95 180 | 951 80X |
| PF 002035 | 20 | 35 | 6 | 30 | 95666 | |
| PF 00251 0 | 20 | 10 | 6 | 50 | 95 181 | 951 81 X |
| PF 00251 0M8 | 25 | 10 | 8 | 50 | 951 81 M8 | 951 81 M8X |
| PF 00251 3 | 25 | 13 | 6 | 50 | 95667 | |
| PF 00251 3M8 | 25 | 13 | 8 | 50 | 95667M8 | |
| PF 00251 5 | 25 | 15 | 6 | 50 | 95 182 | 951 82X |
| PF 00251 5M8 | 25 | 15 | 8 | 50 | 951 82M8 | 951 82M8X |
| PF 00251 7 | 25 | 17 | 6 | 29 | 95668 | |
| PF 00251 7M8 | 25 | 17 | 8 | 29 | 95668M8 | |
| PF 00251 9 | 25 | 19 | 6 | 50 | 95669 | |
| PF 00251 9M8 | 25 | 19 | 8 | 50 | 95669M8 | |
| PF 002520 | 25 | 20 | 6 | 50 | 95 183 | 951 83X |
| PF 002520M8 | 25 | 20 | 8 | 50 | 951 83M8 | 951 83M8X |
| PF 002522 | 25 | 22 | 6 | 50 | 95670 | |
| PF 002522M8 | 25 | 22 | 8 | 50 | 95670M8 | |
| PF 002525 | 25 | 25 | 6 | 50 | 95 184 | 951 84X |
| PF 002525M8 | 25 | 25 | 8 | 50 | 951 84M8 | 951 84M8X |
| PF 002528 | 25 | 28 | 6 | 50 | 95672 | |
| PF 002530 | 25 | 30 | 6 | 50 | 95 185 | 951 85X |
| PF 002530M8 | 25 | 30 | 8 | 50 | 951 85M8 | 951 85M8X |
| PF 002535 | 25 | 35 | 6 | 50 | 95979 | |
| PF 002535M8 | 25 | 35 | 8 | 50 | 95979M8 | |
| PF 002540 | 25 | 40 | 6 | 50 | 95673 | |
| PF 002540M8 | 25 | 40 | 8 | 50 | 95673M8 | |
| PF 00301 0 | 30 | 10 | 8 | 70 | 95674 | |
| PF 00301 5 | 30 | 15 | 8 | 70 | 95674M8 | |
| PF 00301 7 | 30 | 17 | 8 | 40 | 95675 | |
| PF 003020 | 30 | 20 | 8 | 38 | 95 187 | 951 87X |
| PF 003020M6 | 30 | 20 | 6 | 38 | 951 87M6 | 951 87M6X |
| PF 003022 | 30 | 22 | 8 | 70 | 95676 | |
| PF 003023 | 30 | 23 | 8 | 70 | 95677 | |
| PF 003025 | 30 | 25 | 8 | 70 | 95 188 | 951 88X |
| PF 003028 | 30 | 28 | 8 | 70 | 95678 | |
| PF 003030 | 30 | 30 | 8 | 70 | 95 189 | 951 89X |
| PF 003033 | 30 | 33 | 8 | 70 | 95679 | |
| PF 003035 | 30 | 35 | 8 | 70 | 95680 | |
| PF 003038 | 30 | 38 | 8 | 70 | 95681 | |
| PF 003040 | 30 | 40 | 8 | 70 | 95682 | |
| PF 003530 | 35 | 30 | 8 | 70 | 95683 | |
| PF 00401 0 | 40 | 10 | 8 | 125 | 95684 | |
| PF 00401 5 | 40 | 15 | 8 | 125 | 95685 | |
| PF 00401 5M1 0 | 40 | 15 | 10 | 125 | 95685M1 0 | |
| PF 004020 | 40 | 20 | 8 | 125 | 95686 | |
| PF 004020M1 0 | 40 | 20 | 10 | 125 | 95686M1 0 | |
| PF 004025 | 40 | 25 | 8 | 125 | 95 190 | 951 90X |
| PF 004025M1 0 | 40 | 25 | 10 | 125 | 951 90M1 0 | 951 90M1 0X |
| PF 004026 | 40 | 26 | 8 | 125 | 95687 | |
| PF 004026M1 0 | 40 | 26 | 10 | 125 | 95687M1 0 | |
| PF 004028 | 40 | 28 | 8 | 70 | 95688 | |
| PF 004028M1 0 | 40 | 28 | 10 | 70 | 95688M1 0 | |
| PF 004030 | 40 | 30 | 8 | 125 | 95 191 | 951 91 X |
| PF 004030M1 0 | 40 | 30 | 10 | 125 | 951 91 M1 0 | 951 91 M1 0X |
| PF 004035 | 40 | 35 | 8 | 125 | 95 129 | 951 29X |
| PF 004035M1 0 | 40 | 35 | 10 | 125 | 951 29M1 0 | 951 29M1 0X |
| PF 004036 | 40 | 36 | 8 | 125 | 95689 | |
| PF 004036M1 0 | 40 | 36 | 10 | 125 | 95689M1 0 | |
| PF 004040 | 40 | 40 | 8 | 125 | 95 193 | 951 93X |
| PF 004040M1 0 | 40 | 40 | 10 | 125 | 951 93M1 0 | 951 93M1 0X |
| PF 004045 | 40 | 45 | 8 | 125 | 95690 | |
| PF 004045M1 0 | 40 | 45 | 10 | 125 | 95690M1 0 | |
| PF 004530 | 45 | 30 | 8 | 112 | 95043 | |
| PF 004535 | 45 | 35 | 8 | 110 | 95691 | |
| PF 00501 5 | 50 | 15 | 10 | 200 | 95045 | |
| PF 00501 5M8 | 50 | 15 | 8 | 200 | 95045M8 | |
| PF 005020 | 50 | 20 | 10 | 180 | 95 194 | 951 94X |
| PF 005020M8 | 50 | 20 | 8 | 180 | 951 94M8 | 951 94M8X |
| PF 005025 | 50 | 25 | 10 | 200 | 95 195 | 951 95X |
| PF 005025M8 | 50 | 25 | 8 | 200 | 951 95M8 | 951 95M8X |
| PF 005028 | 50 | 28 | 10 | 200 | 95671 | |
| PF 005028M8 | 50 | 28 | 8 | 200 | 95671 M8 | |
| PF 005030 | 50 | 30 | 10 | 130 | 95 196 | 951 96X |
| PF 005030M8 | 50 | 30 | 8 | 130 | 951 96M8 | 951 96M8X |
| PF 005035 | 50 | 35 | 10 | 200 | 95 197 | 951 97X |
| PF 005035M8 | 50 | 35 | 8 | 200 | 951 97M8 | 951 97M8X |
| PF 005040 | 50 | 40 | 10 | 200 | 95 198 | 951 98X |
| PF 005040M8 | 50 | 40 | 8 | 200 | 951 98M8 | 951 98M8X |
| PF 005045 | 50 | 45 | 10 | 200 | 95 199 | 951 99X |
| PF 005045M8 | 50 | 45 | 8 | 200 | 951 99M8 | 951 99M8X |
| PF 005050 | 50 | 50 | 10 | 200 | 95200 | 95200X |
| PF 005050M8 | 50 | 50 | 8 | 200 | 95200M8 | 95200M8X |
| PF 005055 | 50 | 55 | 10 | 200 | 95980 | |
| PF 005055M8 | 50 | 55 | 8 | 200 | 95980M8 | |
| PF 005060 | 50 | 60 | 10 | 200 | 95046 | |
| PF 005060M8 | 50 | 60 | 8 | 200 | 95046M8 | |
| PF 006020 | 60 | 20 | 12 | 285 | 95047 | |
| PF 006020M1 0 | 60 | 20 | 10 | 285 | 95047M1 0 | |
| PF 006022 | 60 | 22 | 12 | 400 | 95048 | |
| PF 006022M1 0 | 60 | 22 | 10 | 400 | 95048M1 0 | |
| PF 006025 | 60 | 25 | 12 | 400 | 95049 | |
| PF 006025M1 0 | 60 | 25 | 10 | 400 | 95049M1 0 | |
| PF 006030 | 60 | 30 | 12 | 200 | 95050 | |
| PF 006030M1 0 | 60 | 30 | 10 | 200 | 95050M1 0 | |
| PF 006035 | 60 | 35 | 12 | 195 | 95051 | |
| PF 006035M1 0 | 60 | 35 | 10 | 195 | 95051 M1 0 | |
| PF 006036 | 60 | 36 | 12 | 300 | 95052 | |
| PF 006036M1 0 | 60 | 36 | 10 | 300 | 95052M1 0 | |
| PF 006040 | 60 | 40 | 12 | 186 | 95053 | |
| PF 006040M1 0 | 60 | 40 | 10 | 186 | 95053M1 0 | |
| PF 006045 | 60 | 45 | 12 | 190 | 95054 | |
| PF 006045M1 0 | 60 | 45 | 10 | 190 | 95054M1 0 | |
| PF 006050 | 60 | 50 | 12 | 185 | 95055 | |
| PF 006050M1 0 | 60 | 50 | 10 | 185 | 95055M1 0 | |
| PF 006060 | 60 | 60 | 12 | 180 | 95056 | |
| PF 006560 | 65 | 60 | 12 | 199 | 95057 | |
| PF 007020 | 70 | 20 | 12 | 400 | 95201 | 95201 X |
| PF 007020M1 0 | 70 | 20 | 10 | 400 | 95201 M1 0 | 95201 M1 0X |
| PF 007025 | 70 | 25 | 12 | 400 | 95202 | 95202X |
| PF 007025M10 | 70 | 25 | 10 | 400 | 95202M1 0 | 95202M1 0X |
| PF 007030 | 70 | 30 | 12 | 400 | 95203 | 95203X |
| PF 007030M10 | 70 | 30 | 10 | 400 | 95203M1 0 | 95203M1 0X |
| PF 007035 | 70 | 35 | 12 | 400 | 95204 | 95204X |
| PF 007035M10 | 70 | 35 | 10 | 400 | 95204M1 0 | 95204M1 0X |
| PF 007040 | 70 | 40 | 12 | 400 | 95205 | 95205X |
| PF 007040M10 | 70 | 40 | 10 | 400 | 95205M1 0 | 95205M1 0X |
| PF 007045 | 70 | 45 | 12 | 400 | 95206 | 95206X |
| PF 007045M10 | 70 | 45 | 10 | 400 | 95206M1 0 | 95206M1 0X |
| PF 007050 | 70 | 50 | 12 | 400 | 95207 | 95207X |
| PF 007050M10 | 70 | 50 | 10 | 400 | 95207M1 0 | 95207M1 0X |
| PF 007070 | 70 | 70 | 12 | 400 | 95058 | |
| PF 007070M10 | 70 | 70 | 10 | 400 | 95058M1 0 | |
| PF 007520 | 75 | 20 | 12 | 650 | 95059 | |
| PF 007525 | 75 | 25 | 12 | 320 | 95060 | |
| PF 007530 | 75 | 30 | 12 | 350 | 95061 | |
| PF 007540 | 75 | 40 | 12 | 385 | 95064 | |
| PF 007550 | 75 | 50 | 12 | 230 | 95066 | |
| PF 007555 | 75 | 55 | 12 | 265 | 95067 | |
| PF 007560 | 75 | 60 | 12 | 117 | 95068 | |
| PF 008025 | 80 | 25 | 14 | 600 | 95209 | |
| PF 008030 | 80 | 30 | 14 | 480 | 95 210 | |
| PF 008040 | 80 | 40 | 14 | 330 | 95211 | |
| PF 008050 | 80 | 50 | 14 | 330 | 95 212 | |
| PF 008060 | 80 | 60 | 14 | 254 | 95 213 | |
| PF 008070 | 80 | 70 | 14 | 500 | 95 214 | |
| PF 008080 | 80 | 80 | 14 | 285 | 95 216 | |
| PF 01 0030 | 100 | 30 | 16 | 1 386 | 95 217 | |
| PF 01 0040 | 100 | 40 | 16 | 480 | 95208 | 95208X |
| PF 01 0045 | 100 | 45 | 16 | 720 | 95 218 | |
| PF 01 0050 | 100 | 50 | 16 | 400 | 95 219 | |
| PF 01 0055 | 100 | 55 | 16 | 380 | 95220 | |
| PF 01 0060 | 100 | 60 | 16 | 380 | 95221 | |
| PF 01 0070 | 100 | 70 | 16 | 380 | 95222 | |
| PF 01 0075 | 100 | 75 | 16 | 350 | 95223 | |
| PF 01 0080 | 100 | 80 | 16 | 353 | 95224 | |
| PF 01 2550 | 125 | 50 | 16 | 736 | 95225 | |
| PF 01 2560 | 125 | 60 | 16 | 736 | 95226 | |
| PF 01 2570 | 125 | 70 | 16 | 736 | 95227 | |
| PF 01 2580 | 125 | 80 | 16 | 736 | 95228 | |
| PF 01 5075 | 150 | 75 | 16 | 1 050 | 95229 | |
| PF 01 5075M20 | 150 | 75 | 20 | 1 050 | 95229M10 | |
| PF 1 001 00 | 100 | 100 | 16 | 800 | 95231 | |
| PF 2001 00 | 200 | 100 | 20 | 1 900 | 95232 | |
Special non-standard sizes available
Our vibration dampers are designed to be adapted to your specific needs. Looking for non-standard screw sizes, threads, diameters or lengths? Contact us: we can create customised solutions. Do you have a special requirement? Call us for a customised product!
