Cylindrical antivibration mounts type C (F-F) are anti-vibration devices designed to absorb vibrations and noise efficiently. Consisting of a cylindrical natural rubber body and galvanised steel armature with female-female mounting, they are perfect for stable and versatile installation. Ideal for industrial machinery, motors and ventilation systems, they offer high elasticity and durability. Available in various hardnesses, they adapt to different applications, ensuring optimal performance in a compact design.
Vibration-damping cylinders with female-female connections (with internal threading on both ends) are used to absorb and dampen vibrations in mechanical systems where reliable fixing by bolts or pins is required.
Their cylindrical shape ensures even load distribution, while the rubber or elastomer material effectively dampens oscillations, reducing vibration and noise transmission between connected elements. These vibration dampers are often used in equipment where it is necessary to minimise the impact of vibrations, for example in motors, pumps, fans or other industrial installations, to prevent wear and improve comfort during use.
The ‘female-female’ connection type allows easy integration into the structure, using existing bolts or screws for fastening. This simplifies assembly, as the anti-vibration mount can be installed between two parts of the equipment by simply screwing the bolts into the threaded holes on both sides. This configuration is particularly useful in systems that require a high degree of flexibility in assembly or frequent replacement of components. In addition, the material of the anti-vibration mount, usually rubber or polymer, is resistant to loads and deformations, making it suitable for use under high stress and varying temperatures.
The use of these vibration dampers helps to extend the life of equipment, protecting it from damage caused by vibration and reducing noise levels. They are particularly in demand in the automotive industry, e.g. for fixing suspension systems, as well as in household appliances and construction machinery, where stability and quietness are crucial. Their compact and versatile design makes them an ideal solution for a wide range of vibration control applications.
Download the Cylindrical antivibration mount type C (F-F) catalogue in pdf format:
| Article | Dimensions | Load (daN) 55Sh | Rocam | Stainless Steel | ||
| øD | h | øC | ||||
| FF 001 31 5 | 13 | 15 | 4 | 6,7 | 95705 | |
| FF 001 320 | 13 | 20 | 5 | 6,7 | 95 710 | |
| FF 001 51 5 | 15 | 15 | 4 | 9 | 95 121 | 951 21 X |
| FF 001 51 5M5 | 15 | 15 | 5 | 9 | 951 21 M5 | 951 21 M5X |
| FF 001 520 | 15 | 20 | 4 | 9 | 95 122 | 951 22X |
| FF 001 520M5 | 15 | 20 | 5 | 9 | 951 22M5 | 951 22M5X |
| FF 001 525 | 15 | 25 | 4 | 9 | 95 712 | |
| FF 001 525M5 | 15 | 25 | 5 | 9 | 9571 2M5 | |
| FF 001 530 | 15 | 30 | 4 | 20 | 95 713 | |
| FF 001 530M5 | 15 | 30 | 5 | 20 | 9571 3M5 | |
| FF 001 532 | 15 | 32 | 4 | 20 | 95 715 | |
| FF 001 532M5 | 15 | 32 | 5 | 20 | 9571 5M5 | |
| FF 001 61 5 | 16 | 15 | 5 | 13,5 | 95 716 | |
| FF 001 620 | 16 | 20 | 5 | 12 | 95 717 | |
| FF 001 625 | 16 | 25 | 5 | 15 | 95 718 | |
| FF 00201 5 | 20 | 15 | 6 | 16 | 95 719 | |
| FF 00201 7 | 20 | 17 | 6 | 30 | 95720 | |
| FF 002020 | 20 | 20 | 6 | 14 | 95 123 | 951 23X |
| FF 002025 | 20 | 25 | 6 | 16 | 90578 | 90578X |
| FF 002030 | 20 | 30 | 6 | 19 | 95 124 | 951 24X |
| FF 002030M8 | 20 | 30 | 8 | 19 | 951 24M8 | 951 24M8X |
| FF 002035 | 20 | 35 | 6 | 16 | 95722 | |
| FF 00251 5 | 25 | 15 | 6 | 50 | 95724 | |
| FF 002520 | 25 | 20 | 6 | 40 | 95725 | 95725X |
| FF 002520M8 | 25 | 20 | 8 | 40 | 95725M8 | 95725M8X |
| FF 002522 | 25 | 22 | 6 | 50 | 95726 | |
| FF 002522M8 | 25 | 22 | 8 | 50 | 95726M8 | |
| FF 002525 | 25 | 25 | 6 | 32,5 | 95 126 | 951 26X |
| FF 002525M8 | 25 | 25 | 8 | 32,5 | 951 26M8 | 951 26M8X |
| FF 002528 | 25 | 28 | 6 | 50 | 95728 | |
| FF 002530 | 25 | 30 | 6 | 40 | 95 127 | 951 27X |
| FF 002530M8 | 25 | 30 | 8 | 40 | 951 27M8 | 951 27M8X |
| FF 002535 | 25 | 35 | 6 | 35 | 95729 | |
| FF 002535M8 | 25 | 35 | 8 | 35 | 95729M8 | |
| FF 002540 | 25 | 40 | 6 | 50 | 95730 | |
| FF 002540M8 | 25 | 40 | 8 | 50 | 95730M8 | |
| FF 003020 | 30 | 20 | 8 | 50 | 95732 | |
| FF 003022 | 30 | 22 | 8 | 70 | 95733 | |
| FF 003023 | 30 | 23 | 8 | 70 | 95734 | |
| FF 003025 | 30 | 25 | 8 | 48 | 95 128 | 951 28X |
| FF 003025M6 | 30 | 25 | 6 | 48 | 951 28M6 | 951 28M6X |
| FF 003028 | 30 | 28 | 8 | 70 | 95736 | |
| FF 003030 | 30 | 30 | 8 | 35 | 90579 | 90579X |
| FF 003030M6 | 30 | 30 | 6 | 35 | 90579M6 | 90579M6X |
| FF 003035 | 30 | 35 | 8 | 70 | 95738 | |
| FF 003040 | 30 | 40 | 8 | 70 | 95740 | |
| FF 003050 | 30 | 50 | 8 | 70 | 95741 | |
| FF 004020 | 40 | 20 | 8 | 125 | 95742 | |
| FF 004020M1 0 | 40 | 20 | 10 | 125 | 95742M1 0 | |
| FF 004025 | 40 | 25 | 8 | 125 | 95 129 | 951 29X |
| FF 004025M1 0 | 40 | 25 | 10 | 125 | 951 29M1 0 | 951 29M1 0X |
| FF 004026 | 40 | 26 | 8 | 125 | 95743 | |
| FF 004028 | 40 | 28 | 8 | 88 | 95744 | |
| FF 004028M1 0 | 40 | 28 | 10 | 88 | 95744M1 0 | |
| FF 004030 | 40 | 30 | 8 | 80 | 90580 | 90580X |
| FF 004030M1 0 | 40 | 30 | 10 | 80 | 90580M1 0 | 90580M1 0 |
| FF 004035 | 40 | 35 | 8 | 125 | 95 130 | |
| FF 004035M1 0 | 40 | 35 | 10 | 125 | 951 30M1 0 | |
| FF 004036 | 40 | 36 | 8 | 125 | 95745 | |
| FF 004036M1 0 | 40 | 36 | 10 | 125 | 95745M1 0 | |
| FF 004040 | 40 | 40 | 8 | 69 | 90581 | 90581 X |
| FF 004040M1 0 | 40 | 40 | 10 | 69 | 90581 M1 0 | 90581 M1 0X |
| FF 004045 | 40 | 45 | 8 | 120 | 95746 | |
| FF 004045M1 0 | 40 | 45 | 10 | 120 | 95746M1 0 | |
| FF 004530 | 45 | 30 | 8 | 112 | 95747 | |
| FF 004535 | 45 | 35 | 8 | 90 | 95748 | |
| FF 005020 | 50 | 20 | 10 | 200 | 95750 | |
| FF 005025 | 50 | 25 | 10 | 200 | 95751 | |
| FF 005026 | 50 | 26 | 10 | 200 | 95752 | |
| FF 005028 | 50 | 28 | 10 | 200 | 95753 | |
| FF 005030 | 50 | 30 | 10 | 130 | 95 131 | 951 31 X |
| FF 005035 | 50 | 35 | 10 | 125 | 95 132 | 951 32X |
| FF 005040 | 50 | 40 | 10 | 120 | 95 133 | 951 33X |
| FF 005045 | 50 | 45 | 10 | 110 | 90582 | 90582X |
| FF 005050 | 50 | 50 | 10 | 100 | 95 134 | 951 34X |
| FF 005050M8 | 50 | 50 | 8 | 100 | 951 34M8 | 951 34M8X |
| FF 006025M1 0 | 60 | 25 | 10 | 400 | 95754M1 0 | |
| FF 006030 | 60 | 30 | 12 | 200 | 95755 | |
| FF 006030M1 0 | 60 | 30 | 10 | 200 | 95755M1 0 | |
| FF 006035 | 60 | 35 | 12 | 195 | 95756 | |
| FF 006035M1 0 | 60 | 35 | 10 | 195 | 95756M1 0 | |
| FF 006036 | 60 | 36 | 12 | 300 | 95757 | |
| FF 006040 | 60 | 40 | 12 | 186 | 95758 | |
| FF 006040M1 0 | 60 | 40 | 10 | 186 | 95758M1 0 | |
| FF 006045 | 60 | 45 | 12 | 190 | 95759 | |
| FF 006045M1 0 | 60 | 45 | 10 | 190 | 95759M1 0 | |
| FF 006050 | 60 | 50 | 12 | 185 | 95760 | |
| FF 006050M1 0 | 60 | 50 | 10 | 185 | 95760M1 0 | |
| FF 006060 | 60 | 60 | 12 | 180 | 95761 | |
| FF 006060M1 0 | 60 | 60 | 10 | 180 | 95761 M1 0 | |
| FF 006550 | 65 | 50 | 12 | 199 | 95762 | |
| FF 007030 | 70 | 30 | 12 | 400 | 95 135 | 951 35X |
| FF 007030M1 0 | 70 | 30 | 10 | 400 | 951 35M1 0 | 951 35M1 0X |
| FF 007035 | 70 | 35 | 12 | 450 | 95 136 | 951 36X |
| FF 007035M1 0 | 70 | 35 | 10 | 450 | 951 36M1 0 | 951 36M1 0X |
| FF 007040 | 70 | 40 | 12 | 400 | 95 137 | 951 37X |
| FF 007040M1 0 | 70 | 40 | 10 | 400 | 951 37M1 0 | 951 37M1 0X |
| FF 007045 | 70 | 45 | 12 | 190 | 95 138 | 951 38X |
| FF 007045M1 0 | 70 | 45 | 10 | 190 | 951 38M1 0 | 951 38M1 0X |
| FF 007050 | 70 | 50 | 12 | 400 | 90583 | 90583X |
| FF 007050M1 0 | 70 | 50 | 10 | 400 | 90583M1 0 | 90583M1 0X |
| FF 007070 | 70 | 70 | 12 | 400 | 95736 | |
| FF 007070M1 0 | 70 | 70 | 10 | 400 | 95736M1 0 | |
| FF 007520 | 75 | 20 | 12 | 400 | 95764 | |
| FF 007525 | 75 | 25 | 12 | 350 | 95765 | |
| FF 007530 | 75 | 30 | 12 | 350 | 95766 | |
| FF 007535 | 75 | 35 | 12 | 500 | 95767 | |
| FF 007540 | 75 | 40 | 12 | 250 | 95768 | |
| FF 007545 | 75 | 45 | 12 | 384 | 95769 | |
| FF 007550 | 75 | 50 | 12 | 230 | 95770 | |
| FF 007550M1 0 | 75 | 50 | 10 | 230 | 95770M1 0 | |
| FF 007555 | 75 | 55 | 12 | 230 | 95701 | |
| FF 007555M1 0 | 75 | 55 | 10 | 230 | 95701 M1 0 | |
| FF 007560 | 75 | 60 | 12 | 265 | 95702 | |
| FF 007560M1 0 | 75 | 60 | 10 | 265 | 95702M1 0 | |
| FF 008040 | 80 | 40 | 14 | 600 | 95703 | |
| FF 008050 | 80 | 50 | 14 | 330 | 95704 | |
| FF 008060 | 80 | 60 | 14 | 254 | 95706 | |
| FF 008070 | 80 | 70 | 14 | 425 | 95707 | |
| FF 008080 | 80 | 80 | 14 | 450 | 95708 | |
| FF 01 0040 | 100 | 40 | 16 | 690 | 90584 | 90584X |
| FF 01 0045 | 100 | 45 | 16 | 632 | 95709 | |
| FF 01 0050 | 100 | 50 | 16 | 686 | 95711 | |
| FF 01 0055 | 100 | 55 | 16 | 380 | 95 714 | |
| FF 01 0060 | 100 | 60 | 16 | 380 | 95 718 | |
| FF 01 0070 | 100 | 70 | 16 | 1 000 | 95721 | |
| FF 01 0075 | 100 | 75 | 16 | 350 | 95723 | |
| FF 01 0080 | 100 | 80 | 16 | 353 | 95725 | |
| FF 01 2550 | 125 | 50 | 16 | 736 | 95727 | |
| FF 01 2560 | 125 | 60 | 16 | 736 | 95731 | |
| FF 01 2570 | 125 | 70 | 16 | 736 | 95735 | |
| FF 01 2580 | 125 | 80 | 16 | 736 | 95737 | |
| FF 01 5055M20 | 150 | 55 | 20 | 1 000 | 95739M20 | |
| FF 01 5060 | 150 | 60 | 16 | 1 060 | 95771 | |
| FF 01 5060M20 | 150 | 60 | 20 | 1 060 | 95771 M20 | |
| FF 01 5075 | 150 | 75 | 16 | 905 | 95773 | |
| FF 01 5075M20 | 150 | 75 | 20 | 905 | 95773M20 | |
| FF 1 001 00 | 100 | 100 | 16 | 500 | 95775 | |
| FF 2001 00 | 200 | 100 | 20 | 1 888 | 95776 | |
| FF 2001 00M1 6 | 200 | 100 | 16 | 1 888 | 95776M1 6 | |
Special non-standard sizes available
We offer customisable vibration dampers to meet the unique needs of your projects. Do you require special sizes, such as non-standard diameters, lengths or threads? Our team is ready to design them. Do you have a specific requirement? Contact us for a customised solution!
